Moving Magnet/Moving Coil Phono preamp with line output
Most of today's amplifiers are built without a specific phono cartridge input. The Phono Box is an ideal phono preamplifier for these hi-fi systems, accepting both MM and MC cartridges. The analogue output of the Phono Box can easily be connected to the line-input of your amplifier.
Pro-Ject Phono Box Preamp key Features
* audiophile-grade phono preamp
* allows you to plug a turntable directly into a stereo system, amplifier, computer, or any other device that takes line level input
* gold plated RCA inputs and outputs
* high quality metal casing offers shielding from both vibration and electromagnetic interference
* new green DC power supply (extremely low idle power usage)
* switch for Moving Magnet (MM) and Moving Coil (MC) cartridges (most cartridges are MM)
* low noise, low distortion
* flat RIAA equalization curve with 60dB of gain (MC), 40 dB gain (MM)
* also available in USB version
Pro-Ject Phono Box Preamp Specs
* Input Impedence MM: 47k ohms / 120pf
* Input Impedence MC: 100 ohms / 120pF
* Gain MM: 40dB
* Output Voltage MM: 300mV / 1 kHz or 3mV
* Gain MC: 60 dB
* Output Voltage MC: 200 mV / 1 kHz or 0.3 mV
* Noise MM: 86 dB (94 dB - A weighted)
* Noise MC: 68 dB (75 dB - A weighted)
* THD: MM 0.01% / MC 0.05%
* Max. Output: 9.5 V
* RIAA EQ Curve Accuracy: 20 Hz - 20 kHz / max 0.5 dB
* Power Consumption: 18 V / 80 mA DC
* Power Supply: 18 V / 500 mA DC
* Dimensions (WHD): 4.1 x 1.4 x 4.1 in., 103 x 36 x 103 mm
* Weight: 1.3 lbs., 570 g
